Metal Reflective Coatings
OPCO produces Metal Reflective Coatings on a wide variety of substrates as a prototype, in short runs or high volume. We coat optics produced in-house as well as customer supplied components.
Applications
- VUV to IR Spectrometer Mirrors
- Electrically conductive (Gold, NiCr, etc.)
- Durable handheld and vehicle-mounted mirrors
- Broad wavelength beamsplitters and ND filters
Custom metal coatings to your specs
- Spectrophotometer coating verification from 190nm to 20µm – VUV verification down to 120nm available
- Vertically integrated in-house manufacturing: – Coating and fabrication in the same building – Fabrication of custom shapes for mirror * substrates – Large inventory of glass substrate materials
- Polarization: S, P or Average
- Angle of Incidence: 0° to 70°
- Substrate Material: Glass, Crystals, Metals, Ceramics, and plastics
- Military Specifications: Mil-C-675, Mil-F-48616, Mil-M-13508, Mil-C-48497
Typical Reflective Coatings produced by OPCO
- Aluminum, Enhanced Al (Al+MgF2, overcoat), Protected Al (SiO, SiO2, and others)
- Enhanced Silver (Ag+oxide overcoat), Protected Silver (Ag+SiO2 and other oxides)
- Bare Gold, Protected Au (Au+SiO, SiO2, oxide overcoats)
- Bare Platinum
- Bare Chromium, Coatings
- Nickel alloys (NiCr, Inconel™)
- Bare Copper
